- Five-stage sequential voltage source module
- Eurorack recreation of Buchla's classic 200-series 245
- Four lanes of five stages, each with their own CV positioning and outputs
- Select each stage via a pulse input or sweep/jump through stages via the analog CV input
- Loop at different stages via the input jack switches
- Each stage sends a pulse output at the top of the module
- Advance to the next stage with an external pulse/clock via the advance in
- Internal clock features a rate control as well as a modulation input and attenuverter
- Manually or CV control the start and stop of the internal clock
- Pulser clock features a pulse output as well as a reference saw wave output
- Pulser's pulse width or "length" can be set or modulated via CV
- Banana jacks replaced with 3.5mm minijacks for full Eurorack integration
Video
Buchla 245t Sequential Voltage Source
Description
TipTop Audio has teamed up with Buchla to faithfully recreate their Model 245t Sequential Voltage Source, bringing the famous five-stage, four-row sequencer into the Eurorack format.
Divided into two sections, the 245t is comprised of a pulser section (a voltage-controlled lock) with transport controls, as well as the main sequencer section, which offers four rows of highly-customisable five-step sequencing.
Divided into two sections, the 245t is comprised of a pulser section (a voltage-controlled lock) with transport controls, as well as the main sequencer section, which offers four rows of highly-customisable five-step sequencing.
Features
Specifications
- Width: 30hp
- Depth: 25mm
- Power: +12V 63mA / -12V 28mA
- https://tiptopaudio.com/manuals/Buchla_&_Tiptop_Audio_245t.pdf
$399.00
